12 – 22 mm Hose Clamp with a Stainless Steel 304 9 mm band With Butterfly Handle – Norma [2 Pieces]

Norma hose clamp with an adjustable range of 12 – 22 mm and with a butterfly handle. The butterfly handle can be twisted to tighten or loosen the hose clamp through the worm gear design.. It has a band width of 9 mm. This hose clamp is made according to DIN 3017-1 standard. The housing material is stainless steel 304. The hose clamp is tightened or loosened by using a screwdriver due to the worm gear design.

Pros:

• Excellent strength and sealing due to 360° clamping

SL-9 series

Hose clamps SL-9 series have a worm gear design and are available with a clamping range from 8-12 to 90-110 mm and with strap width 9 mm.Hose clamps can be used in a wide array of applications to ensure a strong leak-free hose connection. Common applications are for pneumatics, fuel, oil, etc.

The best way to determine the correct hose clamp is to use it to measure the diameter of the hose when it is attached to the fitting. Most hose clamps are suitable for a range of diameters, so try to select a hose clamp that has your hose diameter in the middle of its range.

Specifications

Clamping range (mm) : 12 mm to 22 mm
Strap width (mm) : 9
Material : Stainless steel 304 (1.4301)
Hose clamp feature : With butterfly handle
Standard : DIN 3017-1
