The alternative solution to a cut off saw on cart. Compact – Lightweight – Quiet – Stable
- 6,5 HP Honda gas engine – Blade-ø 350mm – Cutting depth 120 mm
- Adjustable anti vibration handles for operators comfort
- Cutting depth adjustment by handwheel
- Cutting depth indicator
- Front cutting guide
- Parking break
- Lifting frame
- 25 Liter water tank, easy to fill
- Big rear wheels for good chassis clearance
- Durable Poly-V belt for an optimum of power transmission
Specification
| Max Cutting depth | 120 mm |
| Blade diameter | 350 mm |
| Shaft size | 25,4 mm |
| Water tank | 25 Liter |
| Engine | Honda GX200 |
| Engine power: (net power) | 6,5HP/4,8 kW (5,5HP/4,1kW) |
| Shaft speed | 2.730 min-1 |
| Feed motion | Push |
| Cutting depth adjustment | Handwheel |
| Power transmission | Poly-V Belt |
| Hand Arm Vibrations | 4,5 m/s2 |
| Dimensions: (LxWxH) | 650×450×1000 mm |
| Weight | 77 kg |
| Order-No. | 0282 125 6000 |
