This Medium Security Access Door is manufactured with heavy-duty materials to prevent unwanted access for installation in any wall or ceiling surface.
Features
- Secure Door
- Solid Hinge
- Custom Sizing
Specifications
| Model | BMT/BMW/BMP |
|---|---|
| Door | 12-gauge Steel |
| Frame | 12-gauge Steel |
| Size | Min: 8 inches by 8 inches Max: 36 inches by 48 inches |
| Installation | Wall or ceiling application |
| Flange | 1 inch Exposed, Drywall Bead or Plaster Bead |
| Hinge | Concealed Continuous Piano |
| Finish | White Powder Coat |
| Warranty | 1 year |
| Options | Flanges, Latches, and Materials |
Order Guide
| BASE | FLANGE | LATCH | WIDTH | X | LENGTH | OPTIONS |
|---|---|---|---|---|---|---|
| BM | X | |||||
| T – 1 inch Flange W – Drywall Bead P – Plaster Bead | M – Mortise Lock Prep (1-1/8″) P – Pinned Allen Head Cam Latch(es) S – Pinned Allen Head Security Screw(s) D – Detention Lock | Standard Sizes (in.) 8 x 8 22 x 22 10 x 10 22 x 30 12 x 12 24 x 24 12 x 18 24 x 30 12 x 24 24 x 36* 14 x 14 24 x 48* 16 x 16 30 x 30* 16 x 20 30 x 36* 18 x 18 32 x 32* 18 x 24 36 x 36* 20 x 30 36 x 48* | B – Galvannealed M – Masonry Anchors S – Stainless Steel, Type 304 |
