Power Team Threaded 100 Ton Hydraulic Jack 50.8 mm Stroke

This is a Power Team single-acting, spring return, threaded 100 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 50.8 mm and a total height of 219.1 with retracted piston. It has a UN 61/4“-12 male threaded cylinder.

Pros:

• Maximum operating pressure of up to 700 bar
• Comes with an assembled coupling sleeve 9796
• Robust and high-quality multi-purpose hydraulic jack

Specifications

Stroke (mm) : 50.8
Overall height retracted (mm) : 219.1
Internal diameter (mm) : 159
Force (t) : 100
Thread size connection piston rod : UN 61/4-12
Max pressure (bar) : 700
