Power Team Threaded 25 Ton Hydraulic Jack 362.0 mm Stroke

This is a Power Team single-acting, spring return, threaded 25 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 362 mm and a total height of 476.3 with retracted piston. It has a UN 11/2“-16 female threaded piston rod and UN 35/16“-12 male threaded cylinder.

Pros:

• Maximum operating pressure of up to 700 bar
• Comes with an assembled coupling sleeve 9796
• Robust and high-quality multi-purpose hydraulic jack
• Equipped with a threaded piston rod and cylinder

Specifications

Stroke (mm) : 362
Overall height retracted (mm) : 476.3
Internal diameter (mm) : 86
Force (t) : 25
Thread size connection cylinder : UN 11/2-16
Thread size connection piston rod : UN 35/16-12
Max pressure (bar) : 700
