Power Team Threaded 5 Ton Hydraulic Jack 184.2 mm Stroke

This is a Power Team single-acting, spring return, threaded 5 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 184.2 mm and a total height of 273.1 with retracted piston. It has a UNF 3/4“-16 female threaded piston rod and UN 11/2“-16 male threaded cylinder.

Pros:

• Maximum operating pressure of up to 700 bar
• Comes with an assembled coupling sleeve 9796
• Robust and high-quality multi-purpose hydraulic jack
• Equipped with a threaded piston rod and cylinder

Specifications

Stroke (mm) : 184.2
Overall height retracted (mm) : 273.1
Internal diameter (mm) : 38
Force (t) : 5
Thread size connection cylinder : UNF 3/4-16
Thread size connection piston rod : UN 11/2-16
Max pressure (bar) : 700
