Power Team Threaded 55 Ton Hydraulic Jack 158.8 mm Stroke

This is a Power Team single-acting, spring return, threaded 55 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 158.8 mm and a total height of 282.6 with retracted piston. It has a UN 5“-12 male threaded cylinder.

Pros:

• Maximum operating pressure of up to 700 bar
• Comes with an assembled coupling sleeve 9796
• Robust and high-quality multi-purpose hydraulic jack

Specifications

Stroke (mm) : 158.8
Overall height retracted (mm) : 282.6
Internal diameter (mm) : 127
Force (t) : 55
Thread size connection piston rod : UN 5-12
Max pressure (bar) : 700
