Power Team Threaded 75 Ton Hydraulic Jack 155.6 mm Stroke

This is a Power Team single-acting, spring return, threaded 75 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 155.6 mm and a total height of 314.3 with retracted piston. It has a UN 53/4“-12 male threaded cylinder.

Pros:

• Maximum operating pressure of up to 700 bar
• Comes with an assembled coupling sleeve 9796
• Robust and high-quality multi-purpose hydraulic jack

Specifications

Stroke (mm) : 155.6
Overall height retracted (mm) : 314.3
Internal diameter (mm) : 147
Force (t) : 75
Thread size connection piston rod : UN 53/4-12
Max pressure (bar) : 700
