Key Features
High AirflowThe 3 HP motor moves up to 1,543 CFM of filtered air, giving this dust collector the pull needed for planers, table saws, and sanding equipment in a serious woodworking shop. HEPA FiltrationThe HEPA filter captures 99.97% of particles down to 0.3 microns. That matters when you are trying to keep fine airborne dust under control, not just the bigger chips you can see on the floor. Faster MaintenanceA one-hand drum release lever, frameless bag retention, and an integrated vacuum pressure gauge make routine emptying and filter monitoring quicker, so the Powermatic PM2200 Cyclonic Dust Collector spends more time running and less time being serviced.
Overview
The Powermatic PM2200 Cyclonic Dust Collector is a stationary cyclone dust collection system built for serious woodworking shops that need strong airflow and finer air cleanup than a basic bag collector can deliver. This is a cyclonic dust collector designed for capturing chips and fine dust from woodworking machines. Model Number: PM2200. With a 3 HP motor, 230V single-phase power, and HEPA filtration, it is aimed at users who want one machine handling both bulk chip separation and fine airborne dust control.
On the job, the big story is the combination of airflow and filtration. Powermatic rates this unit at up to 1,543 CFM of filtered air, which gives it the capacity needed for common shop machines like planers, table saws, and sanders. The two-stage cyclonic design pulls heavier chips out before they reach the filter, which helps maintain airflow longer and reduces how quickly the filter loads up. That means less drop-off in performance during real shop use.
The HEPA filter is not just a spec line. It captures 99.97% of particles down to 0.3 microns, which is the fine dust that tends to hang in the air and become a real shop air-quality problem. For woodworkers running sanding operations or cutting sheet goods and hardwoods all day, that level of filtration is a practical upgrade over standard collection setups that mainly deal with visible debris.
Powermatic also built the PM2200 around easier day-to-day use. The one-hand drum release lever speeds up bag changes and drum access, which matters once the collector is in regular rotation. The integrated vacuum pressure gauge gives you a quick way to monitor filter condition instead of guessing when service is needed. There is also a frameless bag retention setup using integrated vacuum lines in the drum, which simplifies the lower bag arrangement and helps improve sealing.
From a build standpoint, the all-metal construction is a real advantage on a machine in this size class. Steel construction and a steel impeller help support durability, while the heavier structure is there for more than looks. It helps keep vibration down and supports quieter operation for a 3 HP collector. At roughly 359 to 370 pounds net weight depending on source, this is a substantial shop machine, but caster wheels make it easier to position once assembled.
Hookup flexibility is another strong point. The PM2200 supports multiple connection options, including three 4-inch hose connections or one 8-inch port, so it can fit into different shop layouts and ducting plans. That makes it a better fit for users setting up around individual machines today but who may want broader ducting options later.
This Powermatic dust collector makes the most sense for dedicated woodworkers, furniture builders, cabinet shops, schools, and advanced home shops that run dust-producing machines often enough to justify a serious central collection solution. If you are mainly cleaning up after a miter saw once in a while, this is more machine than you need. If you are feeding a planer, table saw, or wide sanding workflow and want cleaner air plus easier maintenance, this is exactly the kind of upgrade that starts making sense fast.
At a Glance
3 HPMotor Output 1,543 CFMFiltered Airflow 0.3 MicronHEPA Capture Size 230VSingle-Phase Power
Powermatic PM2200 Cyclonic Dust Collector Maintenance Access
This machine is built to do more than pick up chips. It is designed to keep airflow up, manage fine dust, and make routine maintenance less of a chore in a busy woodworking environment.
- Two-stage cyclonic separation removes heavier debris before it reaches the filter
- All-metal construction helps reduce vibration and supports quieter operation
- Caster wheels make positioning easier once the collector is assembled
What’s in the Box
- (1) PM2200 Cyclonic Dust Collector
- (1) Stand
- (1) HEPA Filter Kit
- (1) Owner’s Manual
Key Specifications
| Motor Output | 3 HP |
|---|---|
| Voltage | 230V |
| Phase | Single Phase |
| Air Volume | 1,543 CFM |
| Filtration | HEPA, 99.97% at 0.3 micron |
| Impeller Diameter | 15-13/16 in. |
| Connection Options | (3) 4 in. hoses or (1) 8 in. port |
| Static Pressure | 14.13 WC |
| Sound Rating | 78 dB(A) |
| Collection Bag Capacity | 55 cu. ft. |
| Length | 54.5 in. |
| Width | 32 in. |
| Height | 85.2 in. |
| Weight | 359 lbs |
| Material | Steel |
Compatibility
Hose ConnectionsSupports either three 4-inch hose connections or one 8-inch port for flexible machine hookups and ducting layouts. Electrical RequirementsDesigned for 230V single-phase power. Recommended circuit size is 30 amps. Machine UseBuilt for dust collection from woodworking equipment such as planers, table saws, and sanding equipment.
Built For
Woodworking Cabinet Shops Furniture Building Professional Shops Advanced Home Shops Dust Collection Planer and Table Saw Use Sanding Operations
Pro Tip
Use the vacuum pressure gauge as your maintenance trigger instead of waiting until suction feels weak. On a cyclone setup like the PM2200, staying ahead of filter loading and drum changes helps you keep airflow where it should be.
Warranty & Support
5 Year limited factory warranty.
Tool Nut’s Take
Tool Nut’s Take
Serious dust control for serious woodworking
The Powermatic PM2200 Cyclonic Dust Collector is the kind of shop upgrade you buy when you are done messing around with weak airflow and fine dust hanging in the air.
- Who it’s for: Woodworkers, cabinet shops, schools, and committed home shop users running planers, saws, and sanders on a regular basis.
- Why it stands out: You get a real 3 HP cyclone setup, HEPA filtration down to 0.3 micron, and smart service features like the pressure gauge and one-hand drum release.
- Worth knowing: This is a large 230V stationary machine, so make sure your shop power and floor space match the machine before you bring it in.
Common Questions
- What kind of power does it require? The PM2200 runs on 230V single-phase power and the recommended circuit size is 30 amps.
- How fine is the filtration? The HEPA filter captures 99.97% of particles down to 0.3 micron.
- What machines is it intended to support? Powermatic positions it for woodworking equipment such as planers, table saws, and sanding equipment.
- What hose connection options does it have? It supports either three 4-inch hose connections or one 8-inch port.
