Simpson Strong-Tie DU212 DU Face-Mount Drywall Hanger for 2×12 with SDS Screws

• Testing verifies that the DU hangers do not reduce the two-hour fire wall assembly rating in either 2×4 or 2×6 walls
• DU fire wall hangers are code listed for structural use under ICC-ES ESR-2552
• Hangers have been tested according to ASTM E814 and received F (flame) and T (temperature) ratings for use on one or both sides of the wall in Intertek Design No. SST/WPCF 120-01
• If hangers are installed on both sides of the wall, then it must be a 2×6 wall
• Seat width: 1-9/16 in.
• Height: 11-1/8 in.
• Made from 14-gauge steel
• Galvanized (G90) for extra corrosion resistance

Engineered and tested to perform, Simpson Strong-Tie hangers are manufactured to the highest quality standards for structural strength and safety. DU face-mount hangers are designed for lighter use to carry joist floor loads to a wood stud wall over two layers of 5/8-in. gypsum board (drywall). These hangers install after the drywall is in place.

• Testing verifies that the DU hangers do not reduce the two-hour fire wall assembly rating in either 2×4 or 2×6 walls
• DU fire wall hangers are code listed for structural use under ICC-ES ESR-2552
• Hangers have been tested according to ASTM E814 and received F (flame) and T (temperature) ratings for use on one or both sides of the wall in Intertek Design No. SST/WPCF 120-01
• If hangers are installed on both sides of the wall, then it must be a 2×6 wall
• Seat width: 1-9/16 in.
• Height: 11-1/8 in.
• Made from 14-gauge steel
• Galvanized (G90) for extra corrosion resistance

Install With: Install with (2) 0.148 in. x 1-1/2 in. nails in the joist and (4) 1/4 in. x 3-1/2 in. Strong Drive SDS Heavy-Duty Connector screws in the face (screws included)
